Our X-Band 3D Air Defense System combines cutting-edge 2D electronic scanning radar with full-spectrum counter-UAV jamming, delivering comprehensive protection against aerial threats. Featuring ±30° elevation/±15.5° azimuth electronic scanning + 360° mechanical rotation, this military-grade solution detects stealth targets (0.01m² RCS) at 8km while neutralizing hostile drones within 2km in 3 seconds.
![System Operation: Radar scanning airspace while jamming UAV control signals]
✅ 25km Extended Reach - Detects conventional aircraft (1m² RCS) at maximum range
✅ Cluster Defense - Tracks 200+ targets simultaneously with 0.8m/s velocity resolution
✅ Battlefield Tough - IP67 rating & -40°C~+70°C operation range
✅ Rapid Deployment - 55kg radar head with <10rpm mechanical scan speed
✅ Energy Efficient - 256W transmit power reduces operational costs
| ![Array Icon] Advanced Beam Steering | ![Target Icon] Smart Tracking | ![Chip Icon] Solid-State Reliability |
|---|---|---|
| - Hybrid electronic/mechanical scanning | - Real-time Doppler analysis | - GaN-based TR modules |
| - 15m range resolution | - 20m positioning accuracy | - 100,000+ hour MTBF |
| - Adaptive clutter rejection algorithms | - Threat priority sorting | - Modular field-replaceable units |
| ![Signal Icon] Spectrum Dominance | ![Shield Icon] Instant Neutralization | ![Gear Icon] Fail-Safe Design |
|---|---|---|
| - 20MHz-6GHz broadband coverage | - 3s automatic threat response | - Worm gear self-locking mechanism |
| - 8 programmable focus bands | - 960W smart power allocation | - Military-grade embedded controller |
| - 3x directional + 1x omni antennas | - GPS/GLONASS spoofing capability | - Dual cooling system |
| Detection | Scanning | Physical |
|---|---|---|
| - 0.01m² RCS @8km | - ±15.5° electronic azimuth | - 686×411×145mm size |
| - 0.8-100m/s velocity range | - ±30° electronic elevation | - 55kg weight |
| - 200 concurrent tracks | - 360° mechanical rotation | - 24/48V DC input |
| Coverage | Precision | Durability |
|---|---|---|
| - 2km effective radius | - ≤0.8° bearing accuracy | - IP67 environmental proof |
| - 60+ simultaneous jams | - 3s reaction time | - MIL-STD-810 vibration |
| - 960W peak power | - 8-band selective jamming | - 50G shock resistance |
Detect cruise missiles & stealth drones
Coastal radar cross-section optimization
24/7 airspace monitoring for forward bases
Integrated with SAM systems
Low-probability-of-intercept (LPI) mode
Crowded spectrum environment operation
Protect nuclear plants/power grids
EMP-hardened design
| Capability | Conventional Systems | Our System |
|---|---|---|
| Detection Range | 15km (1m² RCS) | 25km (1m² RCS) |
| Power Consumption | 500W+ | 256W (49% reduction) |
| Target Capacity | 80 tracks | 200+ tracks |
| Deployment Time | 4-6 hours | <2 hours |
| Maintenance Cost | $12k/year | $6.8k/year |
MIL-STD-461F (EMC)
IP67 Dust/Waterproof
CE/FCC Part 15 Compliance
RoHS 3 Directive
